MCS400
CalPanel
|
MCS400
Compact
|
MCS400
DR
|
MCS5
|
System Processor |
MPC5200
|
MPC5200
|
MPC5200
|
MPC5200
|
Clock Speed |
400MHz
|
400MHz
|
400MHz
|
400MHz
|
FPU |
Y
|
Y
|
Y
|
Y
|
Processor Performance |
760 MIPS
|
760 MIPS
|
760 MIPS
|
760 MIPS
|
RAM |
128 MB
|
128 MB
|
128 MB
|
128 MB
|
OS |
VxWorks 5.5
|
VxWorks 5.5
|
VxWorks 5.5
|
VxWorks 5.5
|
Boot Time |
<1s
|
<1s
|
<1s
|
<1s
|
Size in mm |
200x200x104
|
125x70x32
|
150x86x32
|
110x75x22
|
Temp Range |
-40 to +85°C
|
-40 to +85°C
|
-40 to +85°C
|
-40 to +85°C
|
Flash Disk Size |
8GB
|
8GB
|
8GB
|
1GB
|
Circular Buffer |
Y
|
Y
|
Y
|
Y
|
Display |
254*32 VFD
|
5 Digit LED
|
144x40 VFD
|
Status LEDs
|
External Display Interface |
N
|
N
|
N
|
N
|
LAN Interface |
10/100 Mbps
|
10/100 Mbps
|
10/100 Mbps
|
10/100 Mbps
|
WiFi Interface |
External
|
External
|
External
|
External
|
GPRS/GPS |
N
|
Optional
|
Optional
|
Optional
|
USB |
USB 2.0
|
USB 2.0
|
USB 2.0
|
USB 2.0
|
RS232 |
Y
|
Y
|
Y
|
Y
|
SMB Support |
Y
|
Y
|
Y
|
Y
|
CAN Channels |
2+2 Optional
|
2+2 Optional
|
2+2 Optional
|
2+2 Optional
|
CAN Bus Monitoring |
Y
|
Y
|
Y
|
Y
|
CAN Bus Data Acquisition |
Y
|
Y
|
Y
|
Y
|
Software Selectable CAN Bus Termination |
Y
|
Y
|
Y
|
Y
|
I/O Peripherals |
-/-
|
-/-
|
-/-
|
8/8
|
CCP Calibration and Data Acquisition |
up to 20 ECUs
simultaneously
|
up to 20 ECUs
simultaneously
|
up to 20 ECUs
simultaneously
|
up to 20 ECUs
simultaneously
|
XCP Calibration and Data Acquisition |
up to 20 ECUs
simultaneously
|
up to 20 ECUs
simultaneously
|
up to 20 ECUs
simultaneously
|
up to 20 ECUs
simultaneously
|
ECU Flash Programing |
Y
|
Y
|
Y
|
Y
|
Can be used to calibrate ECU without
PC |
Y
|
-
|
-
|
-
|
MMSP Option |
2
|
-
|
2
|
2
|
JTAG 1149.1
|
2
|
-
|
2
|
2
|
RENESAS
AUD / RTD
|
2
|
-
|
2
|
2
|
Infineon
OCDS 1 / 2
|
2
|
-
|
2
|
2
|
Nexus 5001
|
2
|
-
|
2
|
2
|
Memory Emulator POD I/F
|
2
|
-
|
2
|
2
|
I/F
to ultra fast analog Data Acquisition Hardware
|
2
|
-
|
2
|
2
|
FlexRay Option |
2**
|
2**
|
2**
|
1**
|
Model Based Design Support |
Y
|
Y
|
Y
|
Y
|
Number of RPMs |
10
|
10
|
10
|
10
|
Use existing control hardware |
Y
|
Y
|
Y
|
Y
|
Use existing harness |
Y
|
Y
|
Y
|
Y
|
Requires spare ECU processor resources |
N
|
N
|
N
|
N
|
Supports ALL ECUs |
Y
|
Y
|
Y
|
Y
|
Deterministic Real-Time |
Y
|
Y
|
Y
|
Y
|
Latency |
<10us***
|
<10us***
|
<10us***
|
<10us***
|
Program RAM |
128MB
|
128MB
|
128MB
|
128MB
|
Logging memory |
8GB
|
8GB
|
8GB
|
8GB
|
Log RCP Strategy, ECU measurements
and measurements from external data acquisition
together |
Y
|
Y
|
Y
|
Y
|
Display (programmable for strategy
measurement display) |
Y
|
N
|
Y
|
Y
|
Complete Functionality contained in
model |
Y
|
Y
|
Y
|
Y
|
